STEERING COLUMN

FRONT WHEEL FOR SUZUKI GSX 400 1983

HANDLEBAR

FRONT WHEEL Suzuki MOTO 400 GSX 1983 GSX400FD
1
WHEEL, FRONT (1.85X19)

54111-49300-12U   541114930012U

541114930012U
Not available
2
B. BEARING 15X42X13
B. BEARING 15X42X13

08123-63027-000  

08123-6302B-000
 0812363027000

Unit Price

3
SPACER,FR HUB BEARING<br />SPACER
SPACER, FR HUB BEARING
SPACER

54730-18400-000   5473018400000

5473018400000

Unit Price

4
DISCONTINUE

54711-33002-000  

5471133002000
Not available
5
NUT

08314-31128-000  

08314-3112A-000
 0831431128000

Unit Price

6
PIN

04111-30308-000  

04111-3030A-000
 0411130308000

Unit Price

7
DISCONTINUE<br />NUT
DISCONTINUE
NUT

09159-12011-000   0915912011000

0915912011000
Not available
8
SPACER, FR HUB BEARING, R
SPACER, BEARING

54740-18410-000   5474018410000

5474018410000

Unit Price

9
DISCONTINUE<br />SPACER, AXLE (15X22X30)
DISCONTINUE
SPACER, AXLE (15X22X30)

09180-15034-000   0918015034000

0918015034000
Not available
10
WASHER

08322-21128-000  

08322-01127-000
 0832221128000

Unit Price

11
DISCONTINUE<br />DUST SEAL
DISCONTINUE
DUST SEAL

54871-45010-000   5487145010000

5487145010000
Not available
12
54600-18402
BOX, SPEEDOMETER GEAR

54600-18401-000  

5460018401000
Not available
13
DISK, FRONT BRAKE

59211-33200-000   5921133200000

5921133200000
Not available
14
SPROCKET BOLT<br />BOLT
SPROCKET BOLT
BOLT

09100-08140-000   0910008140000

0910008140000

Unit Price

15
DISK BOLT WASHER<br />WASHER
DISK BOLT WASHER
WASHER

09169-08016-000   0916908016000

0916908016000

Unit Price

16
55100-45011
TIRE (3.25S19)

55100-33211-000   5510033211000

5510033211000
Not available
16
TIRE (3.25S19)

55100-33230-000   5510033230000

5510033230000
Not available
17
TUBE, INNER (2.50V19)

55200-15010-000   5520015010000

5520015010000
Not available
18
BALANCER, WHEEL(20G)

55411-45100-000  

55412-17G00-000
 5541145100000

Unit Price

18
BALANCER, WHEEL(10G)

55413-45100-000  

55411-00A00-000
 5541345100000

Unit Price

18
55413-00A01
BALANCER, NO.2 (30G)

55412-45100-000  

5541245100000
Not available
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRONT WHEEL of your Suzuki of GSX. Let us know if you have any questions.
