IGNITION (MODEL K8 / K9) REFER TO FIG.27A(E- 5) FOR MODEL L0

IGNITION (MODEL L0) FOR SUZUKI KINGQUAD 400 2009

ELECTRICAL (MODEL K8 / K9) REFER TO FIG.28A(E- 7) FOR MODEL L0

Item numbers
IGNITION (MODEL L0) Suzuki QUAD 400 KINGQUAD 2009 LT-F400K9(P17)
1
2
3
4
5
6
7
8
9
10
1
STATOR ASSY

32101-27H10-000   3210127H10000

3210127H10000

Unit Price

2
ROTOR ASSY

32102-27H10-000   3210227H10000

3210227H10000

Unit Price

3
CLAMP,GENERATOR LEAD WIRE<br />CLAMP, MAGNETO LEAD NO.1
CLAMP, GENERATOR LEAD WIRE
CLAMP, MAGNETO LEAD NO.1

31497-45000-000   3149745000000

3149745000000

Unit Price

4
NUT, MAGNETO ROTOR

31792-11H00-000   3179211H00000

3179211H00000

Unit Price

5
CLAMP, MAGNETO LEAD
CLAMP, MAGNETO LEAD NO.2

32371-32E00-000   3237132E00000

3237132E00000

Unit Price

6
BOLT(5X10)
BOLT, SENSOR (5X10)

09100-05019-000   0910005019000

0910005019000

Unit Price

7
BOLT(5X10)
BOLT, CLAMP NO.2 (5X10)

09100-05019-000   0910005019000

0910005019000

Unit Price

8
CLAMP(L:65)
CLAMP(L:65)

09404-06429-000  

09404-06039-000
 0940406429000

Unit Price

9
BOLT
BOLT, MAGNETO

01547-0630A-000   015470630A000

015470630A000

Unit Price

10
5MM WOODRUFF KEY<br />KEY, MAGNETO
5MM WOODRUFF KEY
KEY, MAGNETO

08341-31059-000   0834131059000

0834131059000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the IGNITION (MODEL L0) of your Suzuki KINGQUAD 400 2WD of KINGQUAD. Let us know if you have any questions.

Genuine parts for Suzuki 400 KINGQUAD 2009

BODY/FRAME ELECTRICAL INFORMATION ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS OPTIONS

Suzuki 400 KINGQUAD 2009

Select your Suzuki 2009 model

400 KINGQUAD 2009 LT-F400K9(P17)

KINGQUAD 400 2WD

Suzuki KINGQUAD

Displacement: 400 cc
Year: 2009
Model code LT-F400K9(P17)
