WIRING HARNESS (MODEL K3 / K4) REFER TO FIG.30A(F- 4) FOR MODEL K5/K6 IMOBI

WIRING HARNESS (MODEL K5 / K6 IMOBI) FOR SUZUKI BURGMAN 400 2003

WIRING HARNESS (AN400K5 / K6 P37)

Item numbers

HARNESS, WIRING

36610-15GB0-000 3661015GB0000

Not available

COVER, SPEEDOMETER COUPLER
COVER

36618-33E00-000 3661833E00000

$7,97

Unit Price

FUSE (15A)

09481-15501-000 0948115501000

$3,97

Unit Price

FUSE (10A)

09481-10501-000

Not available

RECTIFIER ASSY
DIODE

32800-16A00-000 3280016A00000

$27,97

Unit Price

CLAMP(L:65)

09404-06429-000

09404-06039-000

$3,97

Unit Price

BAND, WIRING HARNESS
CLAMP (L:125)

09407-14403-000 0940714403000

$3,97

Unit Price

CLAMP, WIRING HARNESS
CLAMP (L:165)

09407-18402-000 0940718402000

$3,97

Unit Price

CLAMP
CLAMP (ID:10)

09403-10405-000 0940310405000

$4,97

Unit Price

CLAMP
CLAMP (ID:20)

09403-20403-000 0940320403000

$5,97

Unit Price

CLAMP
CLAMP (ID:25)

09403-25401-000 0940325401000

$5,97

Unit Price

CLAMP
CLAMP (L:145)

09407-14407-000 0940714407000

$5,97

Unit Price

DISCONTINUE
CLAMP

36651-14G00-000 3665114G00000

Not available

CLAMP
CLAMP (L:90)

09407-11402-000 0940711402000

$3,97

Unit Price

CLAMP

09407-12407-000 0940712407000

$5,97

Unit Price

CLIP

09408-00012-000 0940800012000

Not available

SOCKET ASSY
TERMINAL, POWER SOURCE

39410-76F00-P4Z 3941076F00P4Z

$60,97

Unit Price

COVER

39441-76F00-P4Z 3944176F00P4Z

$15,97

Unit Price

LOCK ASSY, STEERING SET

37110-14850-000 3711014850000

Not available

SHUTTER, STEERING LOCK

37155-14GB0-000 3715514GB0000

Not available

LOCK SET

37101-14810-000 3710114810000

Not available

TORX BOLT (5X10)

37159-14G00-000 3715914G00000

$9,97

Unit Price

SCREW (6X20)

09139-06048-000 0913906048000

$3,97

Unit Price

WASHER
WASHER (6.5X18X1.6)

09160-06109-000 0916006109000

$3,97

Unit Price

NUT 6MM

08316-10063-000

08319-31067-000

$3,97

Unit Price

37840-11X52

37840-11X50-000

Not available

BOLT

01550-06203-000

01550-0620B-000

$4,97

Unit Price

RELAY ASSY, SIDE STAND

38740-26E00-000

38740-26E01-000

$37,97

Unit Price

RELAY ASSY, SIDE STAND

38740-26E00-000

38740-26E01-000

$37,97

Unit Price

HORN ASSY

38500-14G00-000 3850014G00000

$89,97

Unit Price

BOLT

01550-08123-000

01550-0812B-000

$4,97

Unit Price

LAMP ASSY, TRUNK BOX

36210-14G00-000 3621014G00000

$162,97

Unit Price

LENS, ROOM LAMP

36212-79001-000 3621279001000

Not available

BULB(12V45/45W, STANLEY, 70281A)
BULB (12V5W)

09471-12073-000

Not available

SCREW

03541-04123-000

03541-0412A-000

$2,97

Unit Price

SWITCH ASSY, TRUNK BOX LAMP

37980-14F00-000 3798014F00000

$102,97

Unit Price

BOLT

07130-05253-000

07130-0525B-000

$4,97

Unit Price

SPACER (5.5X9.5X10)

09180-05301-000 0918005301000

$3,97

Unit Price

WIRE, POWER SOURCE LEAD

36852-14G00-000 3685214G00000

$18,97

Unit Price

DISCONTINUE
WIRE, IGNITION COIL LEAD

36854-14G00-000 3685414G00000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the WIRING HARNESS (MODEL K5/K6 IMOBI) of your Suzuki of BURGMAN. Let us know if you have any questions.
