FUEL TANK AND COVER FRAME

FENDERS, CARRIER AND ABSORBER FOR SUZUKI DR 50 1986

IGNITION (MOTOPLAT)

FENDER, FRONT (YELLOW)

53121-00E00-25Y 5312100E0025Y

Not available

FENDER, FRONT (WHITE)

53121-00E00-BE1 5312100E00BE1

Not available

FENDER, FRONT (BLUE)

58121-00E00-34S 5812100E0034S

Not available

SCREW M6X25 DIN 7985

02142-16255-000 0214216255000

Not available

WASHER A6 DIN 137

09164-06E04-000 0916406E04000

Not available

PLATE ASSY

53130-00E00-E0Z 5313000E00E0Z

Not available

FENDER REAR, FRONT (YELLOW)

63112-00E00-25Y 6311200E0025Y

Not available

FENDER REAR, FRONT (BLUE)

63112-00E00-34S 6311200E0034S

Not available

FENDER REAR, FRONT (WHITE)

63112-00E00-BE1 6311200E00BE1

Not available

FENDER REAR, REAR

63113-00E10-EE3 6311300E10EE3

Not available

NUT 4MM
NUT 14X11.3

09148-04010-000 0914804010000

$2,97

Unit Price

CLAMP(L:65)

09404-06402-000

09404-06039-000

$3,97

Unit Price

CARRIER ASSY

46300-00E00-000 4630000E00000

Not available

BRACKET, CARRIER, RH

46311-00E00-E91 4631100E00E91

Not available

BASE, CARRIER

46312-00E00-EE3 4631200E00EE3

Not available

BRACKET CARRIER, RL

46313-00E00-E91 4631300E00E91

Not available

SCREW M5X16 DIN 912/N

09106-05E04-000 0910605E04000

Not available

SCREW M5X25 DIN 912/N

09106-05E02-000 0910605E02000

Not available

SCREW M6X16 DIN 7985/N

09125-06E05-000 0912506E05000

Not available

WASHER B6 DIN 9021

09160-06E04-000 0916006E04000

Not available

NUT M6 DIN 985

09140-06E02-000 0914006E02000

Not available

ABSORBER (POUS)

62100-00E00-000 6210000E00000

Not available

SCREW M10X45 DIN 931/8G

09100-10E02-000 0910010E02000

Not available

NUT M10 DIN 985

09140-10E01-000 0914010E01000

Not available

WASHER B10 DIN 125

09160-10E01-000 0916010E01000

Not available

SPACER

62171-00E00-000 6217100E00000

Not available

CUSHION

62172-00E00-000 6217200E00000

Not available

ABSORBER (ARMSTRONG) (26)

62100-00E10-000 6210000E10000

Not available

CUSHION

62170-00E01-000 6217000E01000

Not available

SCREW M5X20 DIN 7985/N

09125-05E09-000 0912505E09000

Not available

WASHER 5 DIN 9021

09160-05E03-000 0916005E03000

Not available

08310-0005A

08310-11056-000

Not available

MUD GUARD, REAR FENDER

63331-14A00-NE1 6333114A00NE1

Not available

SCREW M5X15 DIN 7985

09125-05E03-000 0912505E03000

Not available

WASHER B135 DIN 125

09160-05E02-000 0916005E02000

Not available

08310-0005A

08310-11056-000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FENDERS, CARRIER AND ABSORBER of your Suzuki DR 50 BIG of DR. Let us know if you have any questions.
