STAND AND PEDAL BRAKE

SWINGARM - FENDER FOR SUZUKI DR 50 1986

FRONT FORK (POUS)

SWINGING ARM ASSY, REAR (SILVER)

61000-00E1091 6100000E1091

Not available

BUFFER

61132-00E00-000 6113200E00000

Not available

SCREW M6X60 DIN 931

09100-06E05-000 0910006E05000

Not available

WASHER 6 DIN 9021

09160-06E02-000 0916006E02000

Not available

NUT M6 DIN 985

09140-06E02-000 0914006E02000

Not available

BUSH

61133-00E00-000 6113300E00000

Not available

SHAFT

61210-34BA0-E0N 6121034BA0E0N

Not available

NUT M12X1.5 DIN 985

09140-12E03-000 0914012E03000

Not available

WASHER B12 DIN 125

09160-12E01-000 0916012E01000

Not available

SPRING

61341-00E00-000 6134100E00000

Not available

TENSIONER ASSY, CYCLE CHAIN TENSIONER

61342-00E00-E0Z 6134200E00E0Z

Not available

GROMMET

61345-00E00-000 6134500E00000

Not available

SPRING, CYCLE CHAIN TENSIONER

61346-00E00-000 6134600E00000

Not available

SCREW M4X30 DIN 933

09100-04E02-000 0910004E02000

Not available

NUT

08310-11046-000

08310-00043-000

$2,97

Unit Price

SPACER

09180-06060-E0Z 0918006060E0Z

Not available

SCREW M6X30 DIN 931

09100-06E06-000 0910006E06000

Not available

WASHER B6 DIN 125

09160-06E01-000 0916006E01000

Not available

CASE, CHAIN

61311-00E00-EE3 6131100E00EE3

Not available

MUDGUARD, REAR

62111-00E00-EE3 6211100E00EE3

Not available

..SCREW

02142-05125-000 0214205125000

Not available

WASHER B5 DIN 9021

09160-05E03-000 0916005E03000

Not available

WASHER B5 DIN 125

09160-05E04-000 0916005E04000

Not available

08310-0005A

08310-11056-000

Not available

NUT M6 DIN 985

09140-06E02-000 0914006E02000

Not available

SCREW M5X15 DIN 7985

09125-05E06-000 0912505E06000

Not available

ADHESIVE, CHAIN

68211-00E01-000 6821100E01000

Not available

E RING (E 16 DIN 471)

08331-31168-000 0833131168000

Not available

WASHER (16.1X25.6X2)

09160-16E01-000 0916016E01000

Not available

FINISHING WASHER

41366-00E00-E0N 4136600E00E0N

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SWINGARM - FENDER of your Suzuki DR 50 BIG of DR. Let us know if you have any questions.
