LEG SHIELD (MODEL N / P / R / T)

FOOTREST FOR SUZUKI AE 50 1990

FRONT FENDER

Item numbers

SHIELD, LEG REAR (BLACK)

48121-36C01-291 4812136C01291

Not available

DISCONTINUE
SHIELD, LEG REAR (WHITE)

48121-36C01-29L 4812136C0129L

Not available

SHIELD, LEG REAR (PURPLE)

48121-36C01-Z16 4812136C01Z16

Not available

SCREW

03241-05163-000

03241-0516A-000

$2,97

Unit Price

NUT

09148-05020-000 0914805020000

$3,97

Unit Price

SCREW

03241-05123-000

03241-0512A-000

$2,97

Unit Price

NUT

09148-05020-000 0914805020000

$3,97

Unit Price

BOLT(6X16)
BOLT

09111-06065-000 0911106065000

$3,97

Unit Price

BOLT

09111-06066-000 0911106066000

$4,97

Unit Price

01550-0616A
BOLT REFER TO FIG.52A(H-10) FOR MO

01517-06164-000

Not available

WASHER

09169-06034-000

09169-06071-000

$4,97

Unit Price

SCREW

03241-05163-000

03241-0516A-000

$2,97

Unit Price

NUT

09148-05020-000 0914805020000

$3,97

Unit Price

SHIELD, LEG SIDE RH (BLACK)

48285-36C00-291 4828536C00291

Not available

SHIELD, LEG SIDE RH (WHITE)

48285-36C00-29L 4828536C0029L

Not available

SHIELD, LEG SIDE RH (PURPLE)

48285-36C00-Z16 4828536C00Z16

Not available

SHIELD, LEG SHDE RH (BLACK)

48285-36C20-291 4828536C20291

Not available

SHIELD, LEG SIDE RH (WHITE)

48285-36C20-29L 4828536C2029L

Not available

SHIELD, LEG SIDE LH (BLACK)

48286-36C00-291 4828636C00291

Not available

SHIELD, LEG SIDE RH (WHITE)

48286-36C00-29L 4828636C0029L

Not available

SHIELD, LEG SIDE LH (PURPLE)

48286-36C00-Z16 4828636C00Z16

Not available

SHIELD, LEG SIDE LH (BLACK)

48286-36C20-291 4828636C20291

Not available

SHIELD, LEG SIDE RH (WHITE)

48286-36C20-29L 4828636C2029L

Not available

SCREW

03241-05163-000

03241-0516A-000

$2,97

Unit Price

NUT

09148-05020-000 0914805020000

$3,97

Unit Price

SCREW

03541-04163-000

03541-0416A-000

$2,97

Unit Price

NUT

09148-04024-000 0914804024000

$3,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FOOTREST of your Suzuki of AE. Let us know if you have any questions.
