FRONT FORK (MODEL D) REFER TO FIG50 (H-3) FOR MODEL E

FRONT FORK (MODEL E) FOR SUZUKI DR 500 1984

STEERING COLUMN

DAMPER ASSY, RH (BLACK)

51103-37448-019 5110337448019

Not available

DAMPER ASSY, RH (BLUE)

51103-37448-19F 511033744819F

Not available

DAMPER ASSY, LH (BLACK)

51104-37448-019 5110437448019

Not available

DAMPER ASSY, LH (BLUE)

51104-37448-19F 511043744819F

Not available

OUTER TUBE RH

51130-37448-000 5113037448000

Not available

OUTER TUBE LH

51140-37448-000 5114037448000

Not available

DISCONTINUE
DUST SEAL

51173-40500-000 5117340500000

Not available

DISCONTINUE
CASE, DUST SEAL

51149-40500-000 5114940500000

Not available

DISCONTINUE
RING, STOPPER

51156-30400-000 5115630400000

Not available

OIL SEAL

51153-41211-000 5115341211000

Not available

SLIDE METAL

51167-37446-000 5116737446000

Not available

BOOT (BLACK)

51571-37448-019 5157137448019

Not available

BOOT (BLUE)

51571-37448-19F 515713744819F

Not available

DISCONTINUE
BAND

51575-41410-000 5157541410000

Not available

.SCREW

02112-04168-000 0211204168000

Not available

BAND, LH

51573-37411-000 5157337411000

Not available

BOLT, FORK CYLINDER(10X25)
BOLT

51147-16510-000 5114716510000

$6,97

Unit Price

GASKET

51148-41310-000 5114841310000

$3,97

Unit Price

.SCREW

02112-04088-000 0211204088000

Not available

GASKET, DRAIN, PLUG
GASKET

51183-03010-000 5118303010000

Not available

PIECE, OIL LOCK

51195-41210-000 5119541210000

Not available

INNER TUBE

51110-37446-000 5111037446000

Not available

PISTON

31121-37410-000 3112137410000

Not available

CYLINDER

51146-30400-000 5114630400000

Not available

SPRING

51177-37446-000 5117737446000

$8,97

Unit Price

RING

51196-37446-000 5119637446000

Not available

SPRING

51171-37446-000 5117137446000

Not available

DISCONTINUE
GUIDE, SPRING

51172-38010-000 5117238010000

Not available

DISCONTINUE
O RING

51117-16310-000 5111716310000

Not available

CAP

51351-37446-000 5135137446000

Not available

CAP

51294-20400-000 5129420400000

$9,97

Unit Price

VALVE

51293-44400-000 5129344400000

Not available

O RING

51117-14210-000

09280-06005-000

$3,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRONT FORK (MODEL E) of your Suzuki of DR. Let us know if you have any questions.
