RIGHT HAND REAR WHEEL (MODEL K1 / K2)

LEFT HAND REAR WHEEL (MODEL W / X) FOR SUZUKI QUADMASTER 500 2000

LEFT HAND REAR WHEEL (MODEL Y) REFER TO FIG.58B(L-11) FOR MODEL K1/K2

Item numbers
LEFT HAND REAR WHEEL (MODEL W/X) Suzuki QUAD 500 QUADMASTER 2000 LT-F500FY(E3/E28)
1
2
3
3
3
4
5
6
7
8
9
10
11
11
12
13
14
14
15
15
16
16
1
64110-09F21
HUB, REAR WHEEL LH

64110-09F10-000   6411009F10000

6411009F10000
Not available
2
BOLT

09119-10049-000  

09119-10049-XC0
 0911910049000

Unit Price

3
65310-09F11-12Z
RIM, REAR WHEEL (12X8.0AT) (SILVER)

65310-09F00-12Z   6531009F0012Z

6531009F0012Z
Not available
3
65310-09F11-12Z
RIM, REAR WHEEL (12X8.0AT) (GRAY)

65310-09F00-35W   6531009F0035W

6531009F0035W
Not available
4
NUT, 10MM
NUT

09159-10012-000   0915910012000

0915910012000

Unit Price

5
WASHER

09164-18004-000   0916418004000

0916418004000

Unit Price

6
NUT
NUT, HUB

09141-18008-000   0914118008000

0914118008000

Unit Price

7
PIN

04111-40408-000  

04111-4040A-000
 0411140408000

Unit Price

8
CAP, WHEEL CTR

54725-09F00-000  

54725-09F01-000
 5472509F00000

Unit Price

9
DISCONTINUE
AXLE, REAR LH

64712-09F00-000   6471209F00000

6471209F00000
Not available
10
TIRE, REAR (AT25X10-12) (DUNLOP)

65110-09F00-000   6511009F00000

6511009F00000
Not available
11
VALVE ASSY, WHEEL RIM,TR412
VALVE ASSY, WHEEL RIM, TR412

43130-24A00-000   4313024A00000

4313024A00000

Unit Price

12
DISCONTINUE
PLATE, TRAILER TOW

95210-09F00-000   9521009F00000

9521009F00000
Not available
13
PROTECTOR, FINAL CASE

61390-09F00-000   6139009F00000

6139009F00000
Not available
14
BOLT

07120-08163-000  

07120-0816A-000
 0712008163000

Unit Price

15
DISCONTINUE
BOLT, FRONT

07120-08123-000  

0712008123000
Not available
16
BOLT

07120-08163-000  

07120-0816A-000
 0712008163000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
