CRANKCASE

CRANKCASE COVER FOR SUZUKI V-STROM 650 2012

CRANKSHAFT

Item numbers
CRANKCASE COVER Suzuki MOTO 650 V-STROM 2012 DL650AL2(E24)
1
2
3
4
5
5
5
5
5
5
5
5
5
5
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
22
23
23
24
25
26
27
27
27
27
27
27
27
27
28
28
29
29
30
31
32
33
1
COVER, CLUTCH

11340-44H10-000   1134044H10000

1134044H10000

Unit Price

2
LENS, OIL LEVEL CHECK
LENS, OIL LEVEL CHECK

11971-33210-000   1197133210000

1197133210000

Unit Price

3
GASKET, CLUTCH COVER
GASKET, CLUTCH COVER INNER

11482-44H00-000   1148244H00000

1148244H00000

Unit Price

4
PIN
PIN

04211-09149-000   0421109149000

0421109149000

Unit Price

5
BOLT, ST CL COV/ST ID
BOLT (6X35)

09103-06214-000   0910306214000

0910306214000

Unit Price

6
PLUG,ENGINE OIL FILLER<br />PLUG, OIL FILLER
PLUG, ENGINE OIL FILLER
PLUG, OIL FILLER

11971-25D00-000   1197125D00000

1197125D00000

Unit Price

7
O-RING,OIL FILLER<br />O RING (D:3.1,ID:16.8)
O-RING, OIL FILLER
O RING (D:3.1, ID:16.8)

09280-17003-000   0928017003000

0928017003000

Unit Price

8
SEPARATOR, OIL

11343-44H00-000  

11343-44H01-000
 1134344H00000

Unit Price

9
BOLT (6X12)

09106-06098-000   0910606098000

0910606098000

Unit Price

10
COVER, CLUTCH OUTER

11342-11J00-000   1134211J00000

1134211J00000

Unit Price

11
DAMPER, CLUTCH OUTER COVER
DAMPER

11344-11J00-000   1134411J00000

1134411J00000

Unit Price

12
BOLT

02162-06167-000  

01550-06167-000
 0216206167000

Unit Price

13
GASKET<br />GASKET (5.8X13X1.2)
GASKET
GASKET (5.8X13X1.2)

09168-06023-000   0916806023000

0916806023000
Not available
14
COVER, ENGINE SPROCKET INNER

11361-44H00-000   1136144H00000

1136144H00000

Unit Price

15
BOLT

01547-0620A-000   015470620A000

015470620A000

Unit Price

16
BOLT

01547-0635A-000   015470635A000

015470635A000

Unit Price

17
9 X 12 DOWEL PIN<br />PIN
9 X 12 DOWEL PIN
PIN

04211-09129-000   0421109129000

0421109129000

Unit Price

18
COVER, ENGINE SPROCKET OUTER

11371-11J00-000   1137111J00000

1137111J00000

Unit Price

19
BOLT, SEC DRIVE UNIT COVER
BOLT

11372-22H00-000   1137222H00000

1137222H00000

Unit Price

20
SCREW (6X20)
SCREW (6X20)

09139-06028-000   0913906028000

0913906028000

Unit Price

21
SCREW (6X40)

09139-06105-000   0913906105000

0913906105000

Unit Price

22
WASHER
WASHER

09169-06062-000   0916906062000

0916906062000

Unit Price

23
CUSHION
CUSHION

09320-09016-000   0932009016000

0932009016000

Unit Price

24
COVER, MAGNETO

11351-44H00-000   1135144H00000

1135144H00000

Unit Price

25
GASKET, MAGNETO COVER
GASKET, MAGNETO COVER

11483-19F00-000   1148319F00000

1148319F00000

Unit Price

26
PIN
PIN

04211-09149-000   0421109149000

0421109149000

Unit Price

27
BOLT, ST CL COV/ST ID
BOLT (6X35)

09103-06214-000   0910306214000

0910306214000

Unit Price

28
BOLT
BOLT (6X65)

09103-06239-000   0910306239000

0910306239000

Unit Price

29
GASKET<br />GASKET (5.8X13X1.2)
GASKET
GASKET (5.8X13X1.2)

09168-06023-000   0916806023000

0916806023000
Not available
30
PLUG

09259-26011-000   0925926011000

0925926011000

Unit Price

31
O-RING,CRK HOLE PLUG<br />O RING (D:3.1,ID:22.7)
O-RING, CRK HOLE PLUG
O RING (D:3.1, ID:22.7)

09280-22008-000   0928022008000

0928022008000

Unit Price

32
PLUG,OIL<br />PLUG
PLUG, OIL
PLUG

09248-16012-000   0924816012000

0924816012000

Unit Price

33
GASKET OIL GALLERY<br />GASKET (16X22X2)
GASKET OIL GALLERY
GASKET (16X22X2)

09168-16002-000   0916816002000

0916816002000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CRANKCASE COVER of your Suzuki V-STROM 650 of V-STROM. Let us know if you have any questions.
