FOOTREST

REAR FAIRING FOR SUZUKI BOULEVARD 800 2015

HEADLIGHT BOWL

Item numbers
REAR FAIRING Suzuki MOTO 800 BOULEVARD 2015 VL800 L5 (E28)
1
1
3
4
5
5
7
8
9
10
11
12
13
14
14
14
14
15
15
16
17
17
17
17
18
19
20
1
COVER, SIDE, R(BLACK)
COVER, FRAME RH (BLACK)

47110-41F61-YVB   4711041F61YVB

4711041F61YVB

Unit Price

1
COVER, SIDE, R(RED)
COVER, FRAME RH (RED)

47110-41F61-YYG   4711041F61YYG

4711041F61YYG

Unit Price

3
SHIELD, FRAME COVER
.SHIELD, FRAME COVER RH

47166-41F00-000   4716641F00000

4716641F00000

Unit Price

4
MOLDING
.MOLDING, RH

94631-35F00-000   9463135F00000

9463135F00000

Unit Price

5
COVER, SIDE, L(BLACK)
COVER, FRAME LH (BLACK)

47210-41FL1-YVB   4721041FL1YVB

4721041FL1YVB

Unit Price

5
COVER, SIDE, L(RED)
COVER, FRAME LH (RED)

47210-41FL1-YYG   4721041FL1YYG

4721041FL1YYG

Unit Price

7
CUSHION, LUGGAGE BOX
.CUSHION, LH

47217-41F00-000   4721741F00000

4721741F00000

Unit Price

8
COVER, SIDE LWR, R
COVER, SIDE LOWER RH

47130-41F00-000   4713041F00000

4713041F00000

Unit Price

9
COVER, SIDE LWR, L
COVER, SIDE LOWER LH

47231-41F00-000   4723141F00000

4723141F00000

Unit Price

10
SCREW, SIDE COVER LWR, R
SCREW

47133-43H00-000   4713343H00000

4713343H00000

Unit Price

11
CUSHION (8.5X20X8)
CUSHION (8.5X20X8)

09320-08021-000  

09320-08510-000
 0932008021000

Unit Price

12
COVER, SIDE RR, R
COVER, SIDE REAR RH (BLACK)

47141-41F01-019   4714141F01019

4714141F01019

Unit Price

13
COVER, SIDE RR, L
COVER, SIDE REAR LH (BLACK)

47241-41F00-019   4724141F00019

4724141F00019

Unit Price

14
SCREW<br />SCREW (6X20)
SCREW
SCREW (6X20)

09139-06126-000   0913906126000

0913906126000

Unit Price

15
CUSHION(8X26X7)
CUSHION(8X26X7)

09320-08018-000  

09320-08513-000
 0932008018000

Unit Price

16
CUSHION(8X26X7)
CUSHION(8X26X7)

09320-08028-000  

09320-08514-000
 0932008028000

Unit Price

17
CUSHION

09320-09501-000   0932009501000

0932009501000

Unit Price

18
09320-09062
CUSHION

09320-09045-000   0932009045000

0932009045000
Not available
19
LOCK SET, COVER

95700-07860-000  

95700-07861-000
 9570007860000

Unit Price

20
NUT
NUT

08316-1006B-000   083161006B000

083161006B000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the REAR FAIRING of your Suzuki BOULEVARD 800 of BOULEVARD. Let us know if you have any questions.
