CYLINDER HEAD (AVT) FOR SUZUKI BOULEVARD 800 2015

CYLINDER HEAD (REAR)

Item numbers
CYLINDER HEAD (AVT) Suzuki MOTO 800 BOULEVARD 2015 VL800 L5 (E28)
1
2
3
4
4
5
6
6
7
8
9
10
11
12
13
13
14
14
15
15
15
15
15
16
17
18
19
20
22
23
23
24
25
25
26
27
28
29
30
31
31
31
31
31
31
32
33
33
34
34
34
34
34
35
36
37
38
39
40
41
42
43
43
44
45
1
HEAD ASSY, CYLINDER FR
HEAD ASSY, CYLINDER FRONT

11101-39G60-000   1110139G60000

1110139G60000

Unit Price

2
**09206-11004
.PIN (11X14)

09206-11011-000   0920611011000

0920611011000

Unit Price

3
GUIDE, VALVE(OS:0.3)
GUIDE, VALVE (OS 0.3)

11115-41F70-000   1111541F70000

1111541F70000

Unit Price

4
BOLT (6X50)

09103-06304-000   0910306304000

0910306304000

Unit Price

5
BOLT (6X55)

09103-06305-000   0910306305000

0910306305000

Unit Price

6
BOLT

07130-0680B-000   071300680B000

071300680B000

Unit Price

7
GASKET, CYLINDER HEAD WATER
GASKET, CYLINDER HEAD COVER

11123-38A00-000   1112338A00000

1112338A00000

Unit Price

8
GASKET, CYLINDER HEAD FR
GASKET, CYLINDER HEAD FRONT

11141-41F00-000   1114141F00000

1114141F00000

Unit Price

9
BOLT (8X250)

09103-08370-000   0910308370000

0910308370000

Unit Price

10
BOLT (10X155)

09103-10133-000   0910310133000

0910310133000

Unit Price

11
BOLT (10X165)

09103-10134-000   0910310134000

0910310134000

Unit Price

12
WASHER (8.5X24X1.6)
WASHER (8.5X24X1.6)

09160-08130-000   0916008130000

0916008130000

Unit Price

13
WASHER<br />WASHER (10.5X22X2.3)
WASHER
WASHER (10.5X22X2.3)

09160-10039-000   0916010039000

0916010039000

Unit Price

14
BOLT

01547-0625A-000  

01547-0625B-000
 015470625A000

Unit Price

15
BOLT

01547-0630A-000   015470630A000

015470630A000

Unit Price

16
BOLT
BOLT

01547-0640A-000   015470640A000

015470640A000

Unit Price

17
PIN<br />KNOCK PIN
PIN
KNOCK PIN

04211-13189-000   0421113189000

0421113189000

Unit Price

18
BOLT
BOLT

07120-0630B-000   071200630B000

071200630B000

Unit Price

19
CAP, CYLINDER HEAD COVER FR, L
CAP, CYLINDER HEAD COVER FL

11171-41FA0-000   1117141FA0000

1117141FA0000

Unit Price

20
CAP, CYLINDER HEAD COVER FR

11172-41F00-000   1117241F00000

1117241F00000

Unit Price

21
CAP, INSPECTION INTAKE

11175-38A11-000   1117538A11000

1117538A11000

Unit Price

22
CAP, INSPECTION EXHAUST

11176-38A11-000   1117638A11000

1117638A11000

Unit Price

23
GASKET, INSPECTION CAP

11177-38A00-000   1117738A00000

1117738A00000

Unit Price

24
SPACER, CYL HEAD COVER CAP NO.2
SPACER, HEAD COVER CAP

11179-10F10-000   1117910F10000

1117910F10000

Unit Price

25
STUD BOLT

09108-06102-000   0910806102000

0910806102000

Unit Price

26
WASHER (6.5X18X1.6)
WASHER (6.5X18X1.6)

09160-06084-000   0916006084000

0916006084000

Unit Price

27
WASHER, 9.5X20X1.0
WASHER (9.5X20X1)

09160-09016-000   0916009016000

0916009016000

Unit Price

28
PLUG, CAM SHAFT
PLUG (OD:30)

09241-30004-000   0924130004000

0924130004000

Unit Price

29
CUSHION
CUSHION

09320-09016-000   0932009016000

0932009016000

Unit Price

30
CUSHION

09320-13015-000   0932013015000

0932013015000

Unit Price

31
BOLT

01547-0620A-000   015470620A000

015470620A000

Unit Price

32
BOLT,6X55<br />BOLT
BOLT, 6X55
BOLT

01547-06557-000   0154706557000

0154706557000

Unit Price

33
NUT

09159-06093-000   0915906093000

0915906093000

Unit Price

34
DPR9EA-9, NGK
SPARK PLUG (DPR9EA-9)

09482-00330-000   0948200330000

0948200330000

Unit Price

34
DPR8EA-9, NGK

09482-00331-000  

09482-00334-000
 0948200331000

Unit Price

34
PLUG, SPARK(X24EPR-U9)
SPARK PLUG (X24EPR-U9)

09482-00335-000   0948200335000

0948200335000

Unit Price

34
DPR7EA-9, NGK
SPARK PLUG (DPR7EA-9)

09482-00354-000   0948200354000

0948200354000

Unit Price

34
DPR8EA-9, NGK
SPARK PLUG (DPR8EA-9)

09482-00334-000   0948200334000

0948200334000

Unit Price

35
UNION, CYL HEAD OUTLET
UNION, CYLINDER HEAD OUTLET

11181-41F00-000   1118141F00000

1118141F00000

Unit Price

36
GASKET, WATER OUTLET UNION
O RING, OUTLET UNION

11182-38A00-000   1118238A00000

1118238A00000

Unit Price

37
BOLT

07130-0620A-000  

07130-0620B-000
 071300620A000

Unit Price

38
BUSH

09301-08007-000   0930108007000

0930108007000

Unit Price

39
UNION, CYL HEAD JOINT
UNION, CYLINDER HEAD JOINT

17891-41F10-000   1789141F10000

1789141F10000

Unit Price

40
BOLT

07130-0612A-000   071300612A000

071300612A000

Unit Price

41
O RING (D:2.4, ID:15.8)

09280-16005-000   0928016005000

0928016005000

Unit Price

42
HOSE, CYLINDER HEAD JOINT
HOSE, HEAD JOINT

17854-41F01-000   1785441F01000

1785441F01000

Unit Price

43
CLAMP

09402-28513-000   0940228513000

0940228513000

Unit Price

44
SENSOR, WATER TEMP

13650-57F00-000   1365057F00000

1365057F00000

Unit Price

45
WASHER<br />GASKET (12X17X1)
WASHER
GASKET (12X17X1)

09168-12017-000   0916812017000

0916812017000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CYLINDER HEAD (AVT) of your Suzuki BOULEVARD 800 of BOULEVARD. Let us know if you have any questions.
