FRONT MASTER CYLINDER (MODEL L / M / N) REFER TO FIG.52A(J-10) FOR MODEL P/R/T

FRONT MASTER CYLINDER (MODEL P / R / T) FOR SUZUKI VX 800 1996

SWINGARM (E1) REFER TO FIG.54 (K-3) FOR E2,E4,E15,E16,E17,E18,E21,

Item numbers

DISCONTINUE
CYLINDER ASSY, FRONT MASTER

59600-45C20-000 5960045C20000

Not available

PISTON/CUP SET
PISTON & CUP SET

59600-04810-000 5960004810000

$40,97

Unit Price

DIAPHRAGM

59667-49460-000 5966749460000

$11,97

Unit Price

CAP

59669-45C20-000 5966945C20000

Not available

SCREW, RESERVOIR CAP
SCREW

69689-49300-000 6968949300000

$2,97

Unit Price

DISCONTINUE
HOLDER

59671-45C10-000 5967145C10000

Not available

BOLT(6X25)
BOLT

59675-19C00-000 5967519C00000

$6,97

Unit Price

BOLT(6X38)
BOLT, UPPER

59675-19C10-000 5967519C10000

$7,97

Unit Price

PROTECTOR

59664-48B00-000 5966448B00000

$15,97

Unit Price

PLATE, DIAPHRAGM
PLATE

59668-41C00-000 5966841C00000

$13,97

Unit Price

HOSE, FRONT BRAKE

59480-45C10-000 5948045C10000

Not available

UNION

09360-10017-000

09360-10061-000

$10,97

Unit Price

BOLT, BRAKE FLUID

09360-10033-000

09360-10062-000

$11,97

Unit Price

WASHER

09161-10009-000 0916110009000

$3,97

Unit Price

DISCONTINUE
CLAMP, HOSE

59268-45C00-000 5926845C00000

Not available

CLAMP, HOSE

59268-01D10-000 5926801D10000

Not available

BOLT

01517-06125-000

01517-06123-000

$3,97

Unit Price

BOLT

01550-06123-000

01550-0612B-000

$3,97

Unit Price

GUIDE, HOSE

59268-45C10-000 5926845C10000

Not available

WASHER

08322-01063-000

08322-0106A-000

$3,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRONT MASTER CYLINDER (MODEL P/R/T) of your Suzuki of VX. Let us know if you have any questions.
