FRONT FORK (MODEL Z) FIG.47 (G-3) : MODEL D

FRONT FORK (MODEL D) FOR SUZUKI GS-G 1100 1983

STEERING COLUMN (MODEL Z) FIG.49 (G-5) : MODEL D

DISCONTINUED

51110-49470-000 5111049470000

Not available

PISTON
SLIDE METAL

51121-49200-000 5112149200000

$28,97

Unit Price

DISCONTINUED

51130-49400-000 5113049400000

Not available

OUTER TUBE LH

51140-49400-000 5114049400000

Not available

SEAL, OIL

51153-49001-000

51153-08C20-000

$28,97

Unit Price

RING, STOPPER
RING OIL SEAL STOPER

51156-40301-000 5115640301000

$7,97

Unit Price

BOLT, STUD

01411-08308-000

01411-0830A-000

$3,97

Unit Price

PIECE OIL LOCK

51195-49071-000 5119549071000

$22,97

Unit Price

BOLT, FORK CYLINDER(10X25)
F FORK CYLINDER BOLT

51147-16510-000 5114716510000

$6,97

Unit Price

GASKET
FORK CYLINDER GASKET

51148-41310-000 5114841310000

$3,97

Unit Price

SEAL, DUST
DUST SEAL

51173-49002-000 5117349002000

$30,97

Unit Price

SCREW (4X8)

02112-04087-000 0211204087000

$2,97

Unit Price

GASKET, DRAIN, PLUG
DRAIN PLUG GASKET

51183-03010-000 5118303010000

Not available

FORK CYLINDER

51146-49000-000 5114649000000

Not available

RING, PISTON
FORK PISTON RING

51196-49000-000 5119649000000

$15,97

Unit Price

DISCONTINUE
FORK REBOUND SPRING

51177-49000-000 5117749000000

Not available

SPRING FR FORK

51171-49470-000 5117149470000

Not available

DISCONTINUE
FORK SPRING GUIDE

51172-38010-000 5117238010000

Not available

SEAT FORK SPRING

51176-49470-000 5117649470000

Not available

DISCONTINUED

51351-49470-000 5135149470000

Not available

DISCONTINUE
FORK HEAD BLT 0 RING

51117-16310-000 5111716310000

Not available

DISCONTINUE
AXLE HOLDER

51132-49000-000 5113249000000

Not available

NUT

09140-08005-000

09140-08017-000

$3,97

Unit Price

8 MM LOCK WASHER

08321-21088-000

08321-01087-000

$3,97

Unit Price

WASHER

08322-21088-000

08322-01087-000

$3,97

Unit Price

DISCONTINUED

51103-49470-000 5110349470000

Not available

DISCONTINUED

51104-49470-000 5110449470000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRONT FORK (MODEL D) of your Suzuki 1100 GS-G of GS-G. Let us know if you have any questions.
