TAIL LIGHT

WIRING HARNESS FOR SUZUKI DR 125 2009

SWITCHES

Item numbers

HARNESS, WIRING

36610-24H00-000 3661024H00000

Not available

CAP, STARTER RELAY

31861-C48-B10J000 31861C48B10J000

Not available

CAP, BATTERY PLUS

33624-13H00-000 3362413H00000

Not available

DIODE

32800-C15-A00J000 32800C15A00J000

Not available

COVER, WIRING HARNESS

36618-15D20-000

36618-15D21-000

$17,97

Unit Price

GUIDE, WIRING HANRESS

36619-24H00-000 3661924H00000

Not available

CLAMP (L: 98)

D9425-00975-000 D942500975000

Not available

CLAMP (L:188)

D9448-01885-000 D944801885000

Not available

BOLT, WIRING HARNESS

D1557-0612A-000 D15570612A000

Not available

BOX ASSY, FUSE

36740-09301-000

36740-24B01-000

$27,97

Unit Price

FUSE (20A)

09481-20101-000 0948120101000

$2,97

Unit Price

LOCK SET

37000-24840-000 3700024840000

Not available

LOCK ASSY, STEERING

37100-24H00-000 3710024H00000

Not available

BOLT, STEERING LOCK

09119-08100-000

37152-17K00-000

$6,97

Unit Price

SWITCH ASSY, STOP LAMP

37740-45D00-000 3774045D00000

$21,97

Unit Price

SPRING, STOP LAMP

43232-24H00-000 4323224H00000

Not available

CLAMP
CLAMP (L:33)

09407-03401-000 0940703401000

$5,97

Unit Price

37840-44X52

37840-44A20-000

Not available

BOLT, SIDE STAND

D1557-0620B-000 D15570620B000

Not available

HORN ASSY

38500-12F10-000 3850012F10000

Not available

BOLT, HORN

D1557-0812B-000 D15570812B000

Not available

RELAY ASSY, SIDE STAND

38740-26E00-000

38740-26E01-000

$37,97

Unit Price

KEY, BLANK

37146-33E00-000 3714633E00000

$20,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the WIRING HARNESS of your Suzuki DR 125 SM of DR. Let us know if you have any questions.
