CYLINDER

CRANKCASE FOR SUZUKI FL 125 2009

CRANKCASE COVER

Item numbers
CRANKCASE Suzuki SCOOTER 125 FL 2009 FL125SDWK9(P2)
1
2
3
3
3
3
4
4
5
6
6
6
6
7
8
9
10
11
12
13
14
1
CRANKCASE ASSY

11301-16810-000   1130116810000

1130116810000
Not available
2
PIN 11X16<br />PIN
PIN 11X16
PIN

04211-11169-000   0421111169000

0421111169000

Unit Price

3
BOLT

01547-0650B-000  

01547-0650A-000
 015470650B000

Unit Price

4
BOLT,6X55<br />SCREW
BOLT, 6X55
SCREW

01547-06557-000   0154706557000

0154706557000

Unit Price

5
BOLT<br />SCREW
BOLT
SCREW

01547-0665B-000   015470665B000

015470665B000

Unit Price

6
BOLT
SCREW

01547-0675B-000   015470675B000

015470675B000

Unit Price

7
BOLT 10X100
BOLT (L:100)

09103-10110-000   0910310110000

0910310110000

Unit Price

8
NUT
NUT

08319-3110A-000   083193110A000

083193110A000

Unit Price

9
BOLT<br />PLUG, OIL GALLERY
BOLT
PLUG, OIL GALLERY

01547-0612B-000   015470612B000

015470612B000

Unit Price

10
TACH GEAR WASHER<br />GASKET (6.2X11X1.2)
TACH GEAR WASHER
GASKET (6.2X11X1.2)

09168-06004-000   0916806004000

0916806004000

Unit Price

11
GUARD, ENGINE

11470-16H00-000   1147016H00000

1147016H00000
Not available
12
BOLT

01547-0612A-000   015470612A000

015470612A000

Unit Price

13
BOLT

01550-0816A-000   015500816A000

015500816A000

Unit Price

14
SEPARATOR, OIL BREATHER

11186-16H00-000   1118616H00000

1118616H00000
Not available
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CRANKCASE of your Suzuki ADDRESS 125 of FL. Let us know if you have any questions.

Genuine parts for Suzuki 125 FL 2009

BODY/FRAME ELECTRICAL INFORMATION ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS

Suzuki 125 FL 2009

Select your Suzuki 2009 model

125 FL 2009 FL125SDWK9(P2)

ADDRESS 125

Suzuki FL

Displacement: 125 cc
Year: 2009
Model code FL125SDWK9(P2)
