SEAT FOR SUZUKI BURGMAN 150 2002

BACKREST (MODEL K2) REFER TO FIG. 49A (G- 7) FOR MODEL K3

Item numbers

SEAT ASSY

45100-07E00-4HS 4510007E004HS

Not available

SEAT ASSY

45100-07E10-4HS 4510007E104HS

Not available

BACKREST, SEAT

45300-49F00-000 4530049F00000

Not available

CUSHION, BACKREST

45149-14F00-000 4514914F00000

Not available

SPACER, SEAT(6.5X10.5X6)
SPACER, BACKREST

45112-33E00-000 4511233E00000

$9,97

Unit Price

D8322-91065

D8322-91065-000

Not available

NUT

D8313-10065-000 D831310065000

Not available

STRIKER, SEAT LOCK

45210-49F00-000 4521049F00000

Not available

NUT

D8316-10065-000 D831610065000

Not available

CUSHION, SEAT MOUNT REAR

45141-49F00-000 4514149F00000

Not available

SPACER

09180-C06-259J000 09180C06259J000

Not available

MOLDING, SEAT

45211-07E10-000 4521107E10000

Not available

BRACKET, SEAT HINGE UPPER

45250-49F00-000 4525049F00000

Not available

SPRING

45275-49F00-000 4527549F00000

Not available

NUT

D8316-10065-000 D831610065000

Not available

STOPPER, SEAT HINGE

09321-C10-002J000 09321C10002J000

Not available

SCREW

D2126-05125-000 D212605125000

Not available

E RING

D8332-11126-000 D833211126000

Not available

CABLE, SEAT LOCK

45280-49F00-000 4528049F00000

Not available

GUIDE, SEAT LOCK CABLE

45288-49F00-000 4528849F00000

Not available

PLATE, SEAT LOCK NO.2

45289-49F00-000 4528949F00000

Not available

LOCK SET, SEAT NO.2

95700-46F00-000 9570046F00000

Not available

LOCK ASSY, SEAT NO.1

45700-30F00-000 4570030F00000

Not available

BOLT 6X12
BOLT

D7107-06125-000

Not available

D8322-91065

D8322-91065-000

Not available

SCREW

D2116-06165-000

02112-0616A-000

$2,97

Unit Price
