* COLOR CHART *

GASKET SET FOR SUZUKI INTRUDER 1500 2002

CYLINDER HEAD (FRONT)(MODEL W / X / Y) REFER TO FIG.1B(B-5) FOR MODEL K1/K2/K3/K4

Item numbers
GASKET SET Suzuki MOTO 1500 INTRUDER 2002 VL1500K2(E2)
1
1
1
GASKET SET

11400-10850-000  

11400-10853-000
 1140010850000

Unit Price

2
GASKET, CYLINDER HEAD FR
GASKET, CYLINDER HEAD FRONT

11141-10F00-000   1114110F00000

1114110F00000

Unit Price

3
GASKET, CYLINDER HEAD RR
GASKET, CYLINDER HEAD REAR

11142-10F00-000   1114210F00000

1114210F00000

Unit Price

4
GASKET, BREATHER COVER

11177-38B01-H17   1117738B01H17

1117738B01H17

Unit Price

5
GASKET, CYLINDER FR
GASKET, CYLINDER FRONT

11241-10F00-000   1124110F00000

1124110F00000

Unit Price

6
GASKET, CYLINDER RR
GASKET, CYLINDER REAR

11242-10F00-000   1124210F00000

1124210F00000

Unit Price

7
GASKET, CLUTCH COVER

11482-38B10-000  

11482-38B20-000
 1148238B10000

Unit Price

8
GASKET, GENERATOR COVER

11483-10F00-000  

11483-10F10-000
 1148310F00000

Unit Price

9
GASKET, GEAR SHIFT COVER

11485-10F00-000  

11485-10F10-000
 1148510F00000

Unit Price

10
GASKET, EXHAUST PIPE

14181-10F00-000   1418110F00000

1418110F00000

Unit Price

10
14181-45C01
GASKET, EXHAUST PIPE

14181-45C00-000   1418145C00000

1418145C00000
Not available
11
GASKET<br />GASKET (5.8X13X1.2)
GASKET
GASKET (5.8X13X1.2)

09168-06023-000   0916806023000

0916806023000
Not available
12
GASKET,FUEL INJECTOR<br />GASKET (16X212X2)
GASKET, FUEL INJECTOR
GASKET (16X212X2)

09168-14011-000   0916814011000

0916814011000

Unit Price

13
GASKET OIL GALLERY<br />GASKET (16X22X2)
GASKET OIL GALLERY
GASKET (16X22X2)

09168-16002-000   0916816002000

0916816002000

Unit Price

14
GASKET (16X22X2)
GASKET (16X22X2)

09168-16003-000   0916816003000

0916816003000

Unit Price

15
BREATHER PLUG G **S1<br />GASKET (18X24.2X2)
BREATHER PLUG G **S1
GASKET (18X24.2X2)

09168-18003-000   0916818003000

0916818003000

Unit Price

16
O RING<br />O RING (D:1.2,ID:4.0)
O RING
O RING (D:1.2, ID:4.0)

09280-04004-000   0928004004000

0928004004000

Unit Price

17
O RING (D:1.9,ID:12.6)
O RING (D:1.9, ID:12.6)

09280-12009-000   0928012009000

0928012009000

Unit Price

18
O-RING,OIL FILLER<br />O RING (D:3.1,ID:16.8)
O-RING, OIL FILLER
O RING (D:3.1, ID:16.8)

09280-17003-000   0928017003000

0928017003000

Unit Price

19
O-RING,CRK HOLE PLUG<br />O RING (D:3.1,ID:22.7)
O-RING, CRK HOLE PLUG
O RING (D:3.1, ID:22.7)

09280-22008-000   0928022008000

0928022008000

Unit Price

20
O RING (D:1.9, ID:40.7)

09280-41007-000   0928041007000

0928041007000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
