TAIL LIGHT (E22) THIS PAGE TO BE DISUSED IN YOUR MARKET.

TAIL LIGHT (E34) FOR SUZUKI DR 400 1980

ELECTRICAL

LAMP UNIT, TAIL

35720-37260-999 3572037260999

Not available

LAMP UNIT, TAIL

35720-37261-999 3572037261999

Not available

LENS

35712-30560-000 3571230560000

Not available

LENS

35712-30561-000 3571230561000

Not available

DISCONTINUE
GASKET

35713-30510-000 3571330510000

Not available

SCREW

09125-04002-000

02112-04558-000

$2,97

Unit Price

GASKET

35627-43010-000 3562743010000

$3,97

Unit Price

SCREW

35725-32460-000 3572532460000

Not available

WASHER

35727-32410-000 3572732410000

Not available

NUT FIG.42 (H-4) : E16, E18, E22,

08310-11068-000 0831011068000

Not available

LOCK WASHER

08321-21068-000 0832121068000

Not available

BULB (6V, 21/5W)

09471-06034-000 0947106034000

Not available

BRACKET SET

35730-37210-000 3573037210000

Not available

CUSHION

35765-37210-000 3576537210000

Not available

CUSHION

35764-36510-000 3576436510000

Not available

SPACER

35766-37210-000 3576637210000

Not available

CUSHION

35765-32410-000 3576532410000

Not available

DISCONTINUE
SPACER

35766-37120-000 3576637120000

Not available

BOLT, ADJUSTER

01107-06208-000 0110706208000

Not available

BOLT FIG.48 (G-10) : GSX1100XD/EXD FIG.49 (G-11) : GSX1100ESD

01107-06308-000 0110706308000

Not available

WASHER 6.5X10X1.2

09160-06027-000

09160-06077-000

$3,97

Unit Price

F FORK COVER WASHER
WASHER

09169-06016-000 0916906016000

$2,97

Unit Price

NUT FIG.42 (H-4) : E16, E18, E22,

08310-11068-000 0831011068000

Not available

WASHER

08322-21068-000 0832221068000

Not available

GROMMET

09308-07004-000 0930807004000

Not available

DISCONTINUED

35793-37200-000 3579337200000

Not available

CUSHION

35717-37200-000 3571737200000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the TAIL LIGHT (E34) of your Suzuki of DR. Let us know if you have any questions.
