FOOTREST

REAR FAIRING FOR SUZUKI BOULEVARD 800 2017

HEADLIGHT BOWL

Item numbers

COVER, FRAME RH (BLACK)

47110-43HC0-YVB 4711043HC0YVB

Not available

.CUSHION, SIDE RH

47112-39G00-000 4711239G00000

Not available

.CUSHION, FRAME RH

47113-39G00-000 4711339G00000

Not available

MOLDING
.MOLDING, RH

94631-35F00-000 9463135F00000

$10,97

Unit Price

SHIELD, FRAME COVER
.SHIELD, HEAT RH

47166-41F00-000 4716641F00000

$17,97

Unit Price

DISCONTINUE
COVER, FRAME LH (BLACK)

47210-43HA0-YVB 4721043HA0YVB

Not available

CUSHION, LUGGAGE BOX
.CUSHION, SIDE LH

47217-41F00-000 4721741F00000

$11,97

Unit Price

COVER, SIDE LOWER RH

47300-41F00-000 4730041F00000

Not available

.CUSHION, RH

47132-39G00-000 4713239G00000

Not available

COVER, SIDE LOWER LH

47230-41F00-000 4723041F00000

Not available

.CUSHION, LH

47232-41F00-000 4723241F00000

Not available

SCREW, SIDE COVER LWR, R
SCREW

47133-43H00-000 4713343H00000

$8,97

Unit Price

CUSHION (8.5X20X8)

09320-08021-000

09320-08510-000

$4,97

Unit Price

COVER, SIDE REAR RH (BLACK)

47140-41F00-019 4714041F00019

Not available

.CUSHION, RH

47142-39G00-000 4714239G00000

Not available

COVER, SIDE REAR LH (BLACK)

47240-41F00-019 4724041F00019

Not available

.CUSHION, LH

47242-39G00-000 4724239G00000

Not available

SCREW
SCREW (6X20)

09139-06126-000 0913906126000

$6,97

Unit Price

CUSHION(8X26X7)

09320-08018-000

09320-08513-000

$4,97

Unit Price

CUSHION(8X26X7)

09320-08028-000

09320-08514-000

$4,97

Unit Price

CUSHION

09320-09501-000 0932009501000

$3,97

Unit Price

09320-09062
CUSHION

09320-09045-000 0932009045000

Not available

LOCK SET, COVER

95700-07860-000

95700-07861-000

$155,97

Unit Price

NUT

08316-1006B-000 083161006B000

$3,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the REAR FAIRING of your Suzuki BOULEVARD 800 of BOULEVARD. Let us know if you have any questions.
