WATER PUMP

RADIATOR FOR SUZUKI GSX 250 1991

RADIATOR HOSE - EXPANSION TANK

Item numbers
RADIATOR Suzuki MOTO 250 GSX 1991 GSX250FM(E24)
1
2
3
4
5
6
6
7
8
8
9
10
11
12
13
14
14A
15
15
15
15
16
16
17
18
19
20
21
1
RADIATOR ASSY, WATER

17710-24D00-000   1771024D00000

1771024D00000
Not available
2
BOLT (6X25)
BOLT (6X25)

09116-06131-000   0911606131000

0911606131000

Unit Price

3
HOUSING UP SPACER<br />SPACER (6.5X10.5X12)
HOUSING UP SPACER
SPACER (6.5X10.5X12)

09180-07004-000   0918007004000

0918007004000

Unit Price

4
CUSHION, RADIATOR LWR
CUSHION, RADIATOR

17787-19A00-000   1778719A00000

1778719A00000

Unit Price

5
BRACKET, RADIATOR UPPER

17742-24D00-000   1774224D00000

1774224D00000
Not available
6
01580-0612B
BOLT

01177-06125-000  

0117706125000
Not available
7
BRACKET, RADIATOR LOWER

17740-24D01-000   1774024D01000

1774024D01000
Not available
8
BOLT

01117-06255-000  

01550-06253-000
 0111706255000

Unit Price

9
CUSHION,OIL COOLER NO.2<br />CUSHION
CUSHION, OIL COOLER NO.2
CUSHION

16628-27A00-000   1662827A00000

1662827A00000

Unit Price

10
FAN ASSY, RADIATOR

17800-24D01-000   1780024D01000

1780024D01000
Not available
11
FAN

17820-06C00-000   1782006C00000

1782006C00000
Not available
12
SCREW

02112-04063-000  

02112-0406B-000
 0211204063000

Unit Price

13
SHROUD ASSY, FAN

17770-24D01-000   1777024D01000

1777024D01000
Not available
14
SCREW

02112-35103-000  

02112-3510B-000
 0211235103000

Unit Price

14A
SCREW

02142-05083-000  

02142-0508A-000
 0214205083000

Unit Price

15
BOLT

01517-06105-000  

01550-0610B-000
 0151706105000

Unit Price

16
NUT 6MM

08316-10063-000  

08319-31067-000
 0831610063000

Unit Price

17
GUARD, HEAT NO.1

17750-24D00-000   1775024D00000

1775024D00000
Not available
18
GUARD, HEAT NO.2

17781-24D00-000   1778124D00000

1778124D00000
Not available
19
BAND, WIRING HARNESS

09407-11401-000  

09407-14403-000
 0940711401000

Unit Price

20
BAND,WIRING HARNESS<br />CLAMP
BAND, WIRING HARNESS
CLAMP

09407-14403-000   0940714403000

0940714403000

Unit Price

21
LABEL, RADIATOR COOLING FAN

17992-24D00-000   1799224D00000

1799224D00000
Not available
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the RADIATOR of your Suzuki of GSX. Let us know if you have any questions.
