FUEL TANK

FAIRING (MODEL K5) FOR SUZUKI KATANA 50 2005

FAIRING (MODEL K6)

Item numbers
FAIRING (MODEL K5) Suzuki SCOOTER 50 KATANA 2005 AY50AK5
1
1
1
2
2
2
3
3
3
4
5
6
7
8
8
9
10
11
12
13
13
14
14
15
1
COVER, FRAME RH (WHITE)

47111-35E50-0JW   4711135E500JW

4711135E500JW
Not available
1
COVER, FRAME RH (BLACK)

47111-35E50-Y7L   4711135E50Y7L

4711135E50Y7L
Not available
1
COVER, FRAME RH (RED)

47111-35E50-YKC   4711135E50YKC

4711135E50YKC
Not available
2
COVER, FRAME LH (WHITE)

47211-35E50-0JW   4721135E500JW

4721135E500JW
Not available
2
COVER, FRAME LH (BLACK)

47211-35E50-Y7L   4721135E50Y7L

4721135E50Y7L
Not available
2
COVER, FRAME LH (RED)

47211-35E50-YKC   4721135E50YKC

4721135E50YKC
Not available
3
EMBLEM SET

68130-02EC0-0JW   6813002EC00JW

6813002EC00JW
Not available
3
EMBLEM SET

68130-02EC0-Y7L   6813002EC0Y7L

6813002EC0Y7L
Not available
3
EMBLEM SET

68130-02EC0-YKC   6813002EC0YKC

6813002EC0YKC
Not available
4
CUSHION

09320-C08-029J000   09320C08029J000

09320C08029J000
Not available
5
CUSHION

09320-C08-051J000   09320C08051J000

09320C08051J000
Not available
6
WASHER

D8322-01055-000  

08322-0105B-000
 D832201055000

Unit Price

7
SCREW, REAR
SCREW, REAR

D3111-05165-000   D311105165000

D311105165000
Not available
8
BOX, HELMET

92210-02E10-NE2   9221002E10NE2

9221002E10NE2
Not available
8
BOX, HELMET

92211-02E10-NE2   9221102E10NE2

9221102E10NE2
Not available
9
SCREW, FRONT
SCREW, FRONT

D3111-05165-000   D311105165000

D311105165000
Not available
10
SCREW

D1C01-06165-000   D1C0106165000

D1C0106165000
Not available
11
WASHER

09169-C06-045J000   09169C06045J000

09169C06045J000
Not available
12
SCREW, UPPER

D1C01-06165-000   D1C0106165000

D1C0106165000
Not available
13
SPOILER, REAR (WHITE)

47391-35E50-0JW   4739135E500JW

4739135E500JW
Not available
13
SPOILER, REAR (BLACK)

47391-35E50-Y7L   4739135E50Y7L

4739135E50Y7L
Not available
14
WING, REAR SPOILER (WHITE)

47392-35E50-0JW   4739235E500JW

4739235E500JW
Not available
14
WING, REAR SPOILER (BLACK)

47392-35E50-Y7L   4739235E50Y7L

4739235E50Y7L
Not available
15
SCREW

D2116-06205-000  

02112-0620A-000
 D211606205000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FAIRING (MODEL K5) of your Suzuki of KATANA. Let us know if you have any questions.
