LOWER FAIRING (MODEL K5) REFER TO FIG. 33A(E- 12) FOR MODEL K6

LOWER FAIRING (MODEL K6) FOR SUZUKI KATANA 50 2005

FRONT FENDER

Item numbers
LOWER FAIRING (MODEL K6) Suzuki SCOOTER 50 KATANA 2005 AY50AK5
1
2
3
4
5
6
6A
7
8
9
10
10
11
11
12
13
1
SHIELD, LEG SIDE RH

48161-35E00-NE2   4816135E00NE2

4816135E00NE2
Not available
2
SHIELD, LEG SIDE LH

48171-02E00-NE2   4817102E00NE2

4817102E00NE2
Not available
3
SCREW, INNER

03541-05125-000   0354105125000

0354105125000
Not available
4
NUT, HELMET BOX

D91FK-48212-000   D91FK48212000

D91FK48212000
Not available
5
SCREW, INNER LH
SCREW, INNER LH

D3111-05165-000   D311105165000

D311105165000
Not available
6
DISCONTINUE

D1507-06205-000  

D150706205000
Not available
6A
D8322-91065

D8322-91065-000  

D832291065000
Not available
7
SHIELD, LEG SIDE LOWER LH

48172-02E00-NE2   4817202E00NE2

4817202E00NE2
Not available
8
SCREW, LEG SIDE LOWER LH

D3111-05135-000   D311105135000

D311105135000
Not available
9
NUT

D91FK-48212-000   D91FK48212000

D91FK48212000
Not available
10
SHIELD, LEG RR SIDE RH (BLUE)

48141-35E00-YBA   4814135E00YBA

4814135E00YBA
Not available
10
SHIELD, LEG RR SIDE RH (RED)

48141-35E00-YKC   4814135E00YKC

4814135E00YKC
Not available
11
SHIELD, LEG RR SIDE LH (BLUE)

48151-35E00-YBA   4815135E00YBA

4815135E00YBA
Not available
11
SHIELD, LEG RR SIDE LH (RED)

48151-35E00-YKC   4815135E00YKC

4815135E00YKC
Not available
12
SCREW, REAR SIDE LEG FRONT
SCREW, REAR SIDE LEG FRONT

D3111-05165-000   D311105165000

D311105165000
Not available
13
WASHER

D8322-01055-000  

08322-0105B-000
 D832201055000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the LOWER FAIRING (MODEL K6) of your Suzuki of KATANA. Let us know if you have any questions.

Genuine parts for Suzuki 50 KATANA 2005
