Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

FRONT FAIRING (MODEL K5) REFER TO FIG. 31A(E- 9) FOR MODEL K6

FRONT FAIRING (MODEL K6) FOR SUZUKI KATANA 50 2006

FOOTREST

Item numbers
FRONT FAIRING (MODEL K6) Suzuki SCOOTER 50 KATANA 2006 AY50AK6
1
1
1
2
2
3
3A
4
4
5
5
6
7
8
8
9
9
10
11
12
13
14
15
1
SHIELD, LEG FRONT LOWER (BLUE)

48137-35E50-YBA   4813735E50YBA

4813735E50YBA
Not available
1
SHIELD, LEG FRONT LOWER (WHITE

48137-35E50-YBD   4813735E50YBD

4813735E50YBD
Not available
1
SHIELD, LEG FRONT LOWER (RED)

48137-35E50-YKC   4813735E50YKC

4813735E50YKC
Not available
2
SHIELD, LEG FRONT (BLACK)

48111-35E50-Y7L   4811135E50Y7L

4811135E50Y7L
Not available
2
SHIELD, LEG FRONT (BLUE)

48111-35E50-YBA   4811135E50YBA

4811135E50YBA
Not available
3A
WASHER

D8322-01065-000  

08322-0106A-000
 D832201065000

Unit Price

3
WASHER

09689-06158-E0N   0968906158E0N

0968906158E0N
Not available
4
SCREW

D2116-06165-000  

02112-0616A-000
 D211606165000

Unit Price

5
GRILL, LEG FRONT (WHITE/RED)

48112-35E60-M4L   4811235E60M4L

4811235E60M4L
Not available
5
SHIELD, LEG FRONT (RED)

48112-35E60-Y7L   4811235E60Y7L

4811235E60Y7L
Not available
6
SCREW
SCREW

D3111-05165-000   D311105165000

D311105165000
Not available
7
NUT

D913E-04160-000   D913E04160000

D913E04160000
Not available
8
NUT

D91EE-04166-000   D91EE04166000

D91EE04166000
Not available
9
WASHER

D8322-01055-000  

08322-0105B-000
 D832201055000

Unit Price

10
SCREW, UNDER

D3111-05225-000   D311105225000

D311105225000
Not available
11
NUT

D91FK-48212-000   D91FK48212000

D91FK48212000
Not available
12
SCREW
SCREW

D3111-05165-000   D311105165000

D311105165000
Not available
13
WASHER

D8322-01055-000  

08322-0105B-000
 D832201055000

Unit Price

14
SCREW, UNDER

D3111-05195-000   D311105195000

D311105195000
Not available
15
NUT

D91EE-04166-000   D91EE04166000

D91EE04166000
Not available
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRONT FAIRING (MODEL K6) of your Suzuki of KATANA. Let us know if you have any questions.

Genuine parts for Suzuki 50 KATANA 2006

BODY/FRAME ELECTRICAL INFORMATION ENGINE/TRANSMISSION SUSPENSION/BRAKES/WHEELS

Suzuki 50 KATANA 2006

Select your Suzuki 2006 model

50 KATANA 2006 AY50AK6

Suzuki KATANA

Displacement: 50 cc
Year: 2006
Model code AY50AK6
