TAIL LIGHT ASSY FOR SUZUKI DR-Z 400 2015

WIRING HARNESS

Item numbers
TAIL LIGHT ASSY Suzuki MOTO 400 DR-Z 2015 DR-Z400E L5 (E24)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1
LAMP ASSY, RR COMB
LAMP ASSY, REAR COMBINATION

35710-44E21-000   3571044E21000

3571044E21000
Not available
2
.LENS

35712-44E00-000   3571244E00000

3571244E00000
Not available
3
.GASKET

35713-44E00-000   3571344E00000

3571344E00000
Not available
4
BULB(12V1.4W G30)<br />.BULB (12V,21/5W)
BULB(12V1.4W G30)
.BULB (12V, 21/5W)

09471-12083-000   0947112083000

0947112083000

Unit Price

5
.SCREW
.SCREW

03211-04207-000   0321104207000

0321104207000

Unit Price

6
.GASKET
.GASKET

35627-43010-000   3562743010000

3562743010000

Unit Price

7
SPACER, REAR COMB OUTER

35717-29F00-000   3571729F00000

3571729F00000
Not available
8
SPACER, REAR COMB INNER

35717-29F10-000   3571729F10000

3571729F10000
Not available
9
WASHER<br />WASHER (5.5X20X1.2)
WASHER
WASHER (5.5X20X1.2)

09160-05501-000   0916005501000

0916005501000

Unit Price

10
CUSHION
CUSHION

09320-10501-000   0932010501000

0932010501000

Unit Price

11
SCREW

03511-0530A-000   035110530A000

035110530A000
Not available
12
BRACKET, LICENSE

35927-29F20-000   3592729F20000

3592729F20000
Not available
13
WASHER (6.5X20X1.6)
WASHER (6.5X20X1.6)

09160-06088-000   0916006088000

0916006088000

Unit Price

14
SCREW
SCREW

02142-0612A-000  

02142-0612B-000
 021420612A000

Unit Price

15
CUSHION
CUSHION

09321-06026-000   0932106026000

0932106026000

Unit Price

16
REFLECTOR ASSY,RR<br />REFLEX REFLECTOR ASSY, RR
REFLECTOR ASSY, RR
REFLEX REFLECTOR ASSY, RR

35970-07F01-000   3597007F01000

3597007F01000

Unit Price

17
NUT
NUT

08316-1005A-000   083161005A000

083161005A000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
