STARTER MOTOR FOR SUZUKI DR 125 2010

IGNITION

Item numbers
STARTER MOTOR Suzuki MOTO 125 DR 2010 DR125SML0
1
2
2
3
4
5
6
7
8
9
10
11
11
12
12
13
14
15
1
MOTOR ASSY, STARTING

31100-24H00-000   3110024H00000

3110024H00000
Not available
2
O RING

31264-05530-000   3126405530000

3126405530000

Unit Price

3
BOLT
BOLT, THROUGH

31281-25H00-000   3128125H00000

3128125H00000

Unit Price

4
O RING

31156-25H00-000   3115625H00000

3115625H00000

Unit Price

5
SHIM

31361-055A0-000   31361055A0000

31361055A0000

Unit Price

6
PLATE LOCK

31361-25H00-000   3136125H00000

3136125H00000

Unit Price

7
RING,STARTER MOTOR<br />O RING
RING, STARTER MOTOR
O RING

09280-24003-000   0928024003000

0928024003000

Unit Price

8
BRACKET

31150-25H00-000   3115025H00000

3115025H00000
Not available
9
SEAL, OIL
OIL SEAL

31153-05530-000   3115305530000

3115305530000

Unit Price

10
FRAME ASSY

31175-25H00-000   3117525H00000

3117525H00000
Not available
11
BRUSH

31132-25H00-000   3113225H00000

3113225H00000

Unit Price

12
SCREW

31134-25H00-000   3113425H00000

3113425H00000

Unit Price

13
SPRING

31135-25H00-000   3113525H00000

3113525H00000

Unit Price

14
BOLT
BOLT, STG

01547-0630A-000   015470630A000

015470630A000

Unit Price

15
SCREW(5X8)<br />SCREW, STG MOT LEAD (5X8)
SCREW(5X8)
SCREW, STG MOT LEAD (5X8)

09137-05004-000   0913705004000

0913705004000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the STARTER MOTOR of your Suzuki DR 125 SM of DR. Let us know if you have any questions.
