FRONT FORK FOR SUZUKI DR 125 2010

STEERING COLUMN

Item numbers

DAMPER ASSY RH

51103-24H00-000 5110324H00000

Not available

DAMPER ASSY LH

51104-24H00-000 5110424H00000

Not available

TUBE, INNER

51110-24H00-000 5111024H00000

Not available

O RING

51117-03H00-000 5111703H00000

Not available

PISTON

51121-24H00-000 5112124H00000

Not available

TUBE, OUTER RH

51131-24H00-000 5113124H00000

Not available

TUBE, OUTER LH

51141-24H00-000 5114124H00000

Not available

CYLINDER

51146-24H00-000 5114624H00000

Not available

BOLT

51147-03H00-000 5114703H00000

Not available

PACKING

51148-03H00-000 5114803H00000

Not available

BUSH

51152-24H00-000 5115224H00000

Not available

SEAL, OIL

51153-24H00-000 5115324H00000

Not available

RING, SNAP

51156-24H00-000 5115624H00000

Not available

WASHER

51168-24H00-000 5116824H00000

Not available

SPRING, MAIN

51171-24H00-000 5117124H00000

Not available

DUST SEAL

51173-24H00-000 5117324H00000

Not available

SCREW

51175-24H00-000 5117524H00000

Not available

SPACER

51176-24H00-000 5117624H00000

Not available

SPRING, SUB

51177-24H00-000 5117724H00000

Not available

RUBBER, CAP

51189-24H00-000 5118924H00000

Not available

WASHER

51192-24H00-000 5119224H00000

Not available

OIL LOCK

51195-24H00-000 5119524H00000

Not available

RING, PISTON

51196-03H00-000 5119603H00000

Not available

STAY, FORK COVER RH

51431-24H00-000 5143124H00000

Not available

STAY, FORK COVER LH

51440-24H00-000 5144024H00000

Not available

BOLT

01550-0812A-000

01550-0812B-000

$4,97

Unit Price

PROTECTOR, FR FORK RH (BLACK)

51501-24H00-019 5150124H00019

Not available

PROTECTOR, FR FORK RH (BLUE)

51501-24H00-YLW 5150124H00YLW

Not available

PROTECTOR, FR FORK LH (BLACK)

51511-24H00-019 5151124H00019

Not available

PROTECTOR, FR FORK LH (BLUE)

51511-24H00-YLW 5151124H00YLW

Not available

SCREW 5X14
SCREW, FR FORK PROTECTER"

09139-05025-000 0913905025000

$3,97

Unit Price

NUT, FR FORK PROTECTER"

D91EE-0416A-000 D91EE0416A000

Not available

WASHER
WASHER, FR FORK PROTECTER"

09169-05024-000 0916905024000

$3,97

Unit Price

SCREW
SCREW, FR FORK PROTECTER"

03541-0516B-000 035410516B000

$3,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRONT FORK of your Suzuki DR 125 SM of DR. Let us know if you have any questions.
