INDICATORS

TAIL LIGHT FOR SUZUKI GSX 400 1997

WIRING HARNESS

Item numbers
TAIL LIGHT Suzuki MOTO 400 GSX 1997 GSX400V(E30)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
19
20
21
22
23
1
LAMP ASSY, REAR COMBINATION

35710-45D01-000   3571045D01000

3571045D01000
Not available
2
LENS

35712-11501-000   3571211501000

3571211501000
Not available
3
GASKET

35713-11520-000   3571311520000

3571311520000
Not available
4
SCREW
SCREW

03211-04306-000   0321104306000

0321104306000

Unit Price

5
GASKET
GASKET

35627-43010-000   3562743010000

3562743010000

Unit Price

6
REFLECTOR

35714-11521-000   3571411521000

3571411521000
Not available
7
SCREW

03511-04123-000  

03511-0412A-000
 0351104123000

Unit Price

8
PROTECTOR

35716-46D00-000   3571646D00000

3571646D00000
Not available
9
BULB(12V1.4W G30)

09471-12128-000  

09471-12083-000
 0947112128000

Unit Price

10
BULB(12V10W)
BULB

09471-12140-000  

0947112140000
Not available
11
BRACKET, REAR COMBINATION LAMP

35730-23E10-000   3573023E10000

3573023E10000
Not available
12
SPACER<br />WASHER (6.2X12.6X14)
SPACER
WASHER (6.2X12.6X14)

09180-06174-000   0918006174000

0918006174000

Unit Price

13
NUT 6MM

08316-10063-000  

08319-31067-000
 0831610063000

Unit Price

14
CUSHION

09320-09018-000   0932009018000

0932009018000

Unit Price

15
SPACER (6.5X9X10)
SPACER (6.5X9X10)

09180-06307-000   0918006307000

0918006307000

Unit Price

16
WASHER (6.5X20X1.6)
WASHER (6.5X20X1.6)

09160-06088-000   0916006088000

0916006088000

Unit Price

17
08310-0006A
NUT

08310-00063-000  

0831000063000
Not available
18
PROTECTOR (170X95X3.0)
PROTECTOR (170X95X3.0)

33651-37000-000   3365137000000

3365137000000

Unit Price

19
CUSHION, HEAD LAMP HOUSING

51827-12E00-000  

51827-01A00-000
 5182712E00000

Unit Price

20
BRACKET, REAR LICENSE PLATE

35927-08A01-000   3592708A01000

3592708A01000
Not available
21
SCREW

02112-06123-000  

02112-3612A-000
 0211206123000

Unit Price

22
NUT 6MM

08316-10063-000  

08319-31067-000
 0831610063000

Unit Price

23
CUSHION
CUSHION

09321-05019-000   0932105019000

0932105019000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the TAIL LIGHT of your Suzuki of GSX. Let us know if you have any questions.
