SWINGARM

CHAIN GUARD FOR SUZUKI GSX 400 1997

REAR WHEEL

Item numbers
CHAIN GUARD Suzuki MOTO 400 GSX 1997 GSX400V(E30)
1
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
1
CASE, CHAIN

61311-23E00-000   6131123E00000

6131123E00000
Not available
2
SCREW
SCREW

02142-06107-000   0214206107000

0214206107000

Unit Price

3
ABSORBER ASSY, REAR SHOCK RH

62103-23E50-000   6210323E50000

6210323E50000
Not available
3
ABSORBER ASSY, REAR SHOCK RH (SPRING RED)

62103-23E70-000   6210323E70000

6210323E70000
Not available
4
ABSORBER ASSY, REAR SHOCK LH

62104-23E50-000   6210423E50000

6210423E50000
Not available
4
ABSORBER ASSY, REAR SHOCK LH (SPRING RED)

62104-23E70-000   6210423E70000

6210423E70000
Not available
5
BOLT(8X20)
BOLT, UPPER (8X20)

09106-08094-000   0910608094000

0910608094000

Unit Price

6
WASHER, 8.5X30X2.3

09160-08110-000  

09160-08503-000
 0916008110000

Unit Price

7
WASHER, 14.5X30X

09160-14033-000  

09160-14062-000
 0916014033000

Unit Price

8
BOLT(10X45)<br />BOLT, LOWER (10X45)
BOLT(10X45)
BOLT, LOWER (10X45)

09103-10284-000   0910310284000

0910310284000

Unit Price

9
SPACER(10.2X14X20.7)
SPACER

09180-10139-000   0918010139000

0918010139000

Unit Price

10
NUT
NUT

08319-31107-000   0831931107000

0831931107000

Unit Price

11
CAP,MUF SPRT BOLT
CAP, MUF SPRT BOLT

09250-06008-000  

09250-06016-000
 0925006008000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CHAIN GUARD of your Suzuki of GSX. Let us know if you have any questions.
