OIL PUMP

ANTI POLLUTION SYSTEM FOR SUZUKI UE 125 2001

TRANSMISSION (1)

Item numbers
ANTI POLLUTION SYSTEM Suzuki SCOOTER 125 UE 2001 UE125CTK1(P2)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
14
15
1
VALVE ASSY, 2ND AIR REED

18450-41D01-000   1845041D01000

1845041D01000
Not available
2
BRACKET, 2ND AIR REED VALVE

18621-46F00-000   1862146F00000

1862146F00000
Not available
3
SCREW

02112-06123-000  

02112-3612A-000
 0211206123000

Unit Price

4
PIPE, 2ND AIR

18410-46F00-000   1841046F00000

1841046F00000
Not available
5
BOLT, STUD

01421-06163-000  

01421-0616A-000
 0142106163000

Unit Price

6
NUT 6MM

08316-10063-000  

08319-31067-000
 0831610063000

Unit Price

7
GASKET, 2ND AIR PIPE

18441-45C00-000  

18441-45C01-000
 1844145C00000

Unit Price

8
CLEANER ASSY, 2ND AIR

18700-46F00-000   1870046F00000

1870046F00000
Not available
9
CUSHION

18487-46F00-000   1848746F00000

1848746F00000
Not available
10
VALVE ASSY, 2ND AIR SWITCHING

18510-46F00-000   1851046F00000

1851046F00000
Not available
11
HOSE, 2ND AIR VALVE

18521-46F00-000   1852146F00000

1852146F00000
Not available
12
HOSE, 2ND AIR CLNR INLET

18731-46F00-000   1873146F00000

1873146F00000
Not available
13
HOSE, 2ND AIR REED VALVE

18461-46F00-000   1846146F00000

1846146F00000
Not available
14
CLIP, NO.1

18428-46F00-000   1842846F00000

1842846F00000
Not available
15
CLAMP, WIRING HARNESS
CLAMP, 2ND AIR VACUUM HOSE

09407-15401-000   0940715401000

0940715401000

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the ANTI POLLUTION SYSTEM of your Suzuki UE 125 of UE. Let us know if you have any questions.

Genuine parts for Suzuki 125 UE 2001
