CARBURETOR FOR SUZUKI UE 125 2001

AIR FILTER

Item numbers

COVER, DIAPHRAGM

13502-20EK0-000 1350220EK0000

Not available

SCREW

13601-11F00-000 1360111F00000

$4,97

Unit Price

SPRING

13503-20EK0-000 1350320EK0000

Not available

NEEDLE, JET (N425-BPB00)

13383-34F50-000 1338334F50000

Not available

SEAT

13382-14F00-000 1338214F00000

Not available

DIAPHRAGM ASSY

13500-20EK0-000 1350020EK0000

Not available

VALVE, NEEDLE

13370-43E00-000 1337043E00000

Not available

FLOAT

13250-14F00-000 1325014F00000

Not available

PIN, FLOAT

13254-26E00-000 1325426E00000

$5,97

Unit Price

SCREW

13602-43E00-000

Not available

PACKING

13258-14F00-000 1325814F00000

Not available

JET, MAIN (#105)

09491-21031-000 0949121031000

Not available

HOLDER, JET NEEDLE

13342-20EK0-000 1334220EK0000

Not available

JET, SLOW (#38)

09492-38004-000 0949238004000

Not available

SCREW, ADJUST

13279-34FA0-000 1327934FA0000

Not available

SPRING

13271-14F00-000 1327114F00000

Not available

WASHER

13291-26E00-000 1329126E00000

$4,97

Unit Price

O RING

13295-26E00-000 1329526E00000

$6,97

Unit Price

COVER

13488-14F00-000 1348814F00000

Not available

SPRING

13494-14F00-000 1349414F00000

Not available

DIAPHRAGM ASSY

13491-20EK0-000 1349120EK0000

Not available

CAP

13499-14F00-000 1349914F00000

Not available

U RING

13497-14F00-000

13497-14F01-000

$5,97

Unit Price

SCREW

02112-04107-000 0211204107000

$2,97

Unit Price

ELEMENT ASSY, THERMO

13430-20EK0-000 1343020EK0000

Not available

COVER

13433-06F30-000 1343306F30000

Not available

PLATE

13428-06F30-000 1342806F30000

$6,97

Unit Price

SCREW

02112-14087-000 0211214087000

$2,97

Unit Price

HOSE

13683-14F00-000 1368314F00000

Not available

HOSE

13684-20EK0-000 1368420EK0000

Not available

CLIP

09401-05402-000 0940105402000

Not available

31C

U RING

13497-14F00-000

13497-14F01-000

$5,97

Unit Price

31D

SCREW

02112-04107-000 0211204107000

$2,97

Unit Price

31A

SPRING

13481-14F00-000 1348114F00000

Not available

31B

COVER

13484-14F00-000 1348414F00000

Not available

DIAPHRAGM

13482-14F00-000 1348214F00000

Not available

SPRING

13271-26E10-000 1327126E10000

$8,97

Unit Price

SCREW, DRAIN

13247-11F00-000 1324711F00000

Not available

SCREW

02112-04127-000

02112-04128-000

$2,97

Unit Price

34B

5 X 8 CROSS SCREW
SCREW

02142-05087-000 0214205087000

$2,97

Unit Price

34E

SCREW, THROTTLE COVER
SCREW

13602-34F50-000 1360234F50000

$4,97

Unit Price

34A

PLATE

13565-20EK0-000 1356520EK0000

Not available

34C

SCREW

02142-05147-000 0214205147000

Not available

34D

COVER

13578-34F50-000 1357834F50000

Not available

HEATER ASSY, CARBURETOR (15W)

13650-25E01-000 1365025E01000

$34,97

Unit Price

HEATER ASSY, CARBURETOR (25W)

13650-34F00-000 1365034F00000

Not available

THERMO SWITCH, CARB HEATER

13655-16F00-000 1365516F00000

$59,97

Unit Price

THERMO SWITCH, CARB HEATER

13655-25E00-000 1365525E00000

$72,97

Unit Price

PLATE, IDLE ADJUST

13279-34F50-000 1327934F50000

Not available

CLAMP(L:65)

09404-06429-000

09404-06039-000

$3,97

Unit Price

JET, BOOST HOSE

13131-20E00-000 1313120E00000

Not available

99x

CARBURETOR ASSY

13200-34F50-000 1320034F50000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CARBURETOR of your Suzuki UE 125 of UE. Let us know if you have any questions.
