SPEEDOMETER FOR SUZUKI DR 500 1983

PILOT LAMPS

DISCONTINUE
SPEEDOMETER

34110-37200-000 3411037200000

Not available

SPEEDOMETER

34110-37460-000 3411037460000

Not available

KNOB

34124-48540-000 3412448540000

Not available

TACHOMETER

34210-37450-000 3421037450000

Not available

SOCKET

34173-26501-000 3417326501000

Not available

BULB(12V3.4W, STANLEY, A72A)
BULB (6V, 3W)

09471-06053-000 0947106053000

$4,97

Unit Price

BULB(6V, 25/25W, A3627)
BULB (6V, 1.7W)

09471-06052-000

Not available

BRACKET

34950-37450-000 3495037450000

Not available

CUSHION

34189-29330-000 3418929330000

Not available

WASHER, LOCK

08321-21058-000

08321-0105A-000

$2,97

Unit Price

WASHER(5.5X16X1.2)

34181-30520-000

09160-05037-000

$2,97

Unit Price

PLATE

34182-48510-000 3418248510000

Not available

NUT

08310-11058-000

08310-00057-000

$3,97

Unit Price

BOLT FIG.48 (G-10) : GSX1100XD/EXD FIG.49 (G-11) : GSX1100ESD

01107-06308-000 0110706308000

Not available

WASHER

08322-21068-000 0832221068000

Not available

CUSHION

34956-15100-000 3495615100000

$7,97

Unit Price

WASHER(6.5X18X1.6)

09160-06007-000

09160-06084-000

$3,97

Unit Price

NUT FIG.42 (H-4) : E16, E18, E22,

08310-11068-000 0831011068000

Not available

LOCK WASHER

08321-21068-000 0832121068000

Not available

SPACER(6.1X8X12)

09180-06040-000

09180-06249-000

$3,97

Unit Price

CABLE ASSY, SPEEDOMETER

34910-30912-000

34910-45115-000

$49,97

Unit Price

DISCONTINUED

34930-05200-000 3493005200000

Not available

.BOLT, DRAIN

01107-08128-000 0110708128000

Not available

8 MM LOCK WASHER

08321-21088-000

08321-01087-000

$3,97

Unit Price

WASHER

08322-11088-000

08322-01087-000

$3,97

Unit Price

34940-05300
CABLE, TACHOMETER

34940-37421-000

Not available

CLAMP(L:65)

09404-06401-000

09404-06039-000

$3,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SPEEDOMETER of your Suzuki of DR. Let us know if you have any questions.
