SWINGARM

CHAIN GUARD FOR SUZUKI DR 500 1983

REAR WHEEL

CHAIN GUARD Suzuki MOTO 500 DR 1983 DR500SD(E1)

1

CHAIN CASE

61311-37200-000 6131137200000

Not available

2

REINFOCEMENT

61380-37200-000 6138037200000

Not available

3

BOLT, FRONT

01107-06108-000 0110706108000

Not available

4

BOLT(6X8)

09100-06092-000

09100-06157-000

$4,97

Unit Price

5

CHAIN CASE WASHER

09169-06025-000

09169-06010-000

$4,97

Unit Price

6

BOLT, ADJUSTER

01107-06208-000 0110706208000

Not available

7

WASHER

08322-21068-000 0832221068000

Not available

8

CHAIN CASE, END

61330-37200-000 6133037200000

Not available

9

BOLT, FRONT

01107-06108-000 0110706108000

Not available

10

NUT FIG.42 (H-4) : E16, E18, E22,

08310-11068-000 0831011068000

Not available

11

CHAIN CASE WASHER

09169-06025-000

09169-06010-000

$4,97

Unit Price

12

SHOCK ABSORBER, REAR

62100-37420-000 6210037420000

Not available

13

BOLT(10X40)
BOLT, UPPER (8X35)

09103-10044-000 0910310044000

$6,97

Unit Price

14

DISCONTINUE
BOLT, LOWER (8X38)

09103-10045-000 0910310045000

Not available

15

NUT, FRONT

08310-22108-000 0831022108000

Not available

16

NUT

08319-31108-000

08319-31107-000

$4,97

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CHAIN GUARD of your Suzuki of DR. Let us know if you have any questions.
